ASTM A743 CF8m Casting
  • ASTM A743 CF8m Casting - 0 ASTM A743 CF8m Casting - 0
  • ASTM A743 CF8m Casting - 1 ASTM A743 CF8m Casting - 1
  • ASTM A743 CF8m Casting - 2 ASTM A743 CF8m Casting - 2

ASTM A743 CF8m Casting

As the professional manufacture, we would like to provide you ASTM A743 CF8m Casting. CF8M is a cast austenitic material for pressure containing parts, which covered by ASTM A351 and ASTM A743 and ASTM A744 standard.
CF8M Chemical Requirements in those three standards as bellow, little difference:

Send Inquiry

Product Description

ASTM A351 Standard Specification for Castings, Austenitic, for Pressure-Containing Parts:


Carbon: 0.08 max

Manganese: 1.50 max

Silicon: 1.50 max

Sulfur: 0.040 max

Phosphorus: 0.040 max

Chromium: 18.0-21.0

Nickel: 9.0-12.0

Molybdenum: 2.0-3.0

Tensile Strength: min 70ksi(485Mpa)

Yield Strength: min 30ksi (205Mpa)

Elongation in 2in. or 50mm: min 30.0%


CF-8M is a molybdenum bearing modification of CF8 alloy and is the cast equivalent of wrought AISI 316 Stainless steel. The presence of molybdenum increases the general corrosion resistance and the resistance to pitting by chlorides. The alloy is used in mildly acidic and alkaline conditions and for handling citric, oxalic and phosphoric acids.


APPLICATIONS

Impellers, propellers, pump casings, valve bodies, press plates.


WELDABILITY

CF-8M may be welded by the SMAW, GTAW and GMAW processes. Electrodes Preheat None


Production Process

We have updated our production line for making ASTM A743 CF8m Casting

Our production process include resin sand molding line, shell molding line, green sand casting and lost wax investment casting production process.

Machining Workshop

We have full set line of machining facilities, various CNC equipment and Machining Center can meet customers’ requirements. After machining, the casting parts will be completed. Then, they will be inspected and packed for delivery and shipment.

Quality Control

Checking the raw material after they reach our factory------- Incoming quality control

Checking the details before the production line operated

Have full inspection and routing inspection during mass production---In process quality control

Checking the goods after they are finished---- Final quality control

Checking the goods after they are finished-----Outgoing quality control

Packing and Delivery

Packaging of ASTM A743 CF8m Casting can be customized based on customer requirements to meet the different needs, such as plastic bag, carton box, wooden case, crate, etc.
